USB |
SKU:
JU-H20111-S1
USB 3.0 to HDMI/DVI Multi Monitor Video Adapter
USB Video Adapter
USB 5Gbps
HDMI / DVI
1600x1200
TAA Compliant
Regular price
$89.99
Unit price
/
Unavailable
Shipping calculated at checkout.
USB 3.0 to HDMI/DVI Multi Monitor Video Adapter is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
High-Performance Chipset
High-Performance Chipset
Crystal Clear HD Resolutions
Crystal Clear HD Resolutions
Versatile Display Modes
Versatile Display Modes
Multi-Monitor Expansion
Multi-Monitor Expansion
Bus Powered & Hot-Pluggable
Bus Powered & Hot-Pluggable
-
45 Days Free Return
-
2 Years Warranty
-
Lifetime Technical Support
No content found
| Hardware | |
| Chipset | MCT Trigger 5 T5-302 |
| Video | |
| Standard | HDMI 2.1, SuperSpeed USB 3.0, and USB 2.0 compliant |
| Resolution | Supports standard and widescreen (16:9 and 16:10) aspect ratio Supports 32-bit color depth at 1920 x 1200 (16:10), 2048 x 1152 (16:9), and 1600 x 1200 (4:3) resolutions |
| Display Features | Display rotation: 0°, 90°, 180°, and 270° Display modes: Primary, Extended and Mirror |
| Scalability | Connects up to 6 adapters per system |
| Power | USB bus powered and hot-pluggable |
| System Requirements | - Desktop or notebook computer with an available USB 2.0/3.0 port (USB 3.0 recommended) - Windows® 10 (32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2008 R2 - Mac OS X® 10.12 / 10.11 / 10.10 / 10.9 / 10.8 / 10.7 / 10.6 |
| Interface | |
| USB to HDMI Adapter | 1x 9-pin, Type A, USB 3.0, male, input 1x 19-pin, HDM, female, output |
| HDMI to DVI Adapter | 1x 19-pin, HDMI, male, input 1x DVI, female, output |
| Package Contents | 1x USB 3.0 to HDMI/DVI Multi Monitor Video Adapter 1x HDMI-to-DVI adapter 1x Driver CD 1x Installation guide |
| Product | |
| Dimensions (L) x (H) x (W) | 2.98″ x1.67″ x 0.61″ 7.57 cm x 4.24 cm x 1.55 cm |
| Weight | 0.11 lb (0.05 kg) |
| Color | Black |
| Unit Package | |
| Dimensions (L) x (H) x (W) | 8.86″ x 5.83″ x 2.17″ 22.50 cm x 14.81 cm x 5.51 cm |
| Weight | 0.37 lb (0.17 kg) |
| Master Carton | |
| Dimensions (L) x (H) x (W) | 18.31″ x 17.72″ x 12.99″ 46.51 cm x 45.01 cm x |
| Weight | 18.74 lbs (8.50 kg) |
| Quantity | 40 pcs/ctn |
| Certifications/Standards | FCC, CE, RoHS |
| UPC Code | 662774-014593 |
| Warranty | 5 years |
| Country of origin | China |
No content found
Manuals
Drivers (Hardware Version: 1)
- Windows 10 (32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/64-bit)Driver version: v20.01.0117.0179
- MAC OS X 10.11 / 10.10 / 10.9 / 10.8Driver version: v2.1.0321
- Windows XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / Server 2008 R2Driver version: v15.01.0211.0179
- MAC OS X 10.6 / 10.7Driver version: v1.8.29
- MAC OS X 10.12 / 10.11 / 10.10Driver version: v2.16.0902
- MAC OS X 10.13.3* / 10.12 / 10.11*Note: Our adapter DOES NOT work with the latest Mac OS 10.13.4 to 10.13.6 update. It's recommended to stay with 10.13.3 or earlier
