AV-Converter/Adapter |
SKU:
CE-H21811-S1
HDMI to VGA + Audio Converter
HDMI In / VGA+Audio Out
1080p 60Hz
3.5mm Audio
Compact Design
6.75Gbps
Regular price
$49.99
Unit price
/
Unavailable
Shipping calculated at checkout.
HDMI to VGA + Audio Converter is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
HDMI to VGA Converter
HDMI to VGA Converter
Up to 1080p
Up to 1080p
PC Resolution
PC Resolution
Audio Extraction
Audio Extraction
HDCP Compliant
HDCP Compliant
No content found
| Hardware | |
| Chipset | Lontium LT8511A |
| Video | |
| HDMI | 1x input |
| VGA | 1x output |
| Bandwidth | Up to 6.75 Gbps |
| Resolution | - Up to UXGA (1600x1200) and WUXGA (1920x1200) PC graphics resolutions - Up to 2.25GHz data ratio *Note: This product does not allow HDCP enabled/protected signals from source devices such as Blu-ray players or PS3 game consoles to pass through to non-HDCP compliant displays. |
| Audio | 3.5mm stereo audio |
| Interface | 1x 19-pin, HDMI, Type A, female, input 1x 15-pin, D-Sub VGA, female, output 1x 3.5mm audio jack, Analog stereo audio, output |
| Power Adapter | |
| Input | 100-240VAC, 50 / 60Hz |
| Output | DC 5V / 1A |
| Package Contents | 1x HDMI to VGA + Audio Converter 1x Power adapter (5V/1A) 1x HDMI cable, 47" (1.2m) 1x Installation guide |
| Certifications/Standards | FCC, CE, RoHS |
| UPC Code | 662774-017020 |
| Warranty | 3 years limited |
| Country of Origin | China |
| Product | |
| Dimensions (L) x (H) x (W) | 2.64″ x 0.98″ x 1.77″ 6.71 cm x 2.49 cm x 4.50 cm |
| Weight | 0.11 lb (0.05 kg) |
| Color | Black |
| Housing | Plastic |
| Unit Package | |
| Dimensions (L) x (H) x (W) | 7.81″ x 2.94″ x 5.56″ 19.84 cm x 7.47 cm x 14.12 cm |
| Weight | 0.75 lb (0.34 kg) |
| Master Carton | |
| Dimensions (L) x (H) x (W) | 16.14″ x 12.20″ x 11.81″ 41.00 cm x 30.99 cm x 30.00 cm |
| Weight | 12.57 lbs (5.70 kg) |
| Quantity | 14 pcs/ctn |
| Environmental Conditions | |
| Operating Temperature | 32° to 113° F |
| Storage Temperature | -4° to 140° F |
| Relative Humidity | < 80% RH |
