DVI over CAT5e Extender
DVI over CAT5e Extender is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
DVI Extender
DVI Extender
Video Resolution
Video Resolution
Compact Transmitter
Compact Transmitter
EQ Control
EQ Control
1080i & 1080p Support
1080i & 1080p Support
DVI over CAT5e Extender
Estimated shipping by May 25, 2026
-
45 Days Free Return
-
2 Years Warranty
-
Lifetime Technical Support
| Stansard | DVI 1.1 compliant, single-link DV |
| Video Bandwidth | 1.65 Gbps |
| Distance | 1024 x 768 60Hz (XGA): 60m / 200ft 1600 x 1200 60Hz (UXGA): 30m / 100ft |
| Transmitter Unit (TX) | 1x DVI-D (digital only) 1x RJ-45 |
| Receiver Unit (RX) | 1x RJ-45 1x DVI-D (digital only) |
| Power Consumption | 5 Watts (max) |
| Package Contents | 1x DVI over CAT5e Extender Kit 1x Power adapter (5V, 2A) 1x Screw kit 1x Quick installation guide |
| Product | |
| Transmitter Unit (TX) | |
| Dimensions (L) x (H) x (W) | 1.97″ x 1.57″ x 0.87" 5.00 cm x 3.99 cm x 2.21 cm |
| Weight | 0.11 lb (0.05 kg) |
| Color | Black |
| Housing Material | Metal |
| Receiver Unit (RX) | |
| Dimensions (L) x (H) x (W) | 3.23″ x 2.44″ x 0.94″ 8.20 cm x 6.20 cm x 2.39 cm |
| Weight | 0.40 lb (0.18 kg) |
| Color | Black |
| Housing Material | PVC |
| Transmitter Unit (TX) | |
| Dimensions (L) x (H) x (W) | 1.97″ x 1.57″ x 0.87" 5.00 cm x 3.99 cm x 2.21 cm |
| Weight | 0.11 lb (0.05 kg) |
| Receiver Unit (RX) | |
| Dimensions (L) x (H) x (W) | 3.23″ x 2.44″ x 0.94″ 8.20 cm x 6.20 cm x 2.39 cm |
| Weight | 0.40 lb (0.18 kg) |
| Unit Package | |
| Dimensions (L) x (H) x (W) | 10.38″ x 3.06″ x 3.88″ 26.37 cm x 7.77 cm x 9.86 cm |
| Weight | 1.23 lbs (0.56 kg) |
| Master Carton | |
| Dimensions (L) x (H) x (W) | 16.94″ x 14.13″ x 11.44″ 43.03 cm x 35.89 cm x 29.06 cm |
| Weight | 14.11 lbs (6.40 lbs) |
| Quantity | 10 pcs/ctn |
| Certifications/Standards | FCC, CE, RoHS, TAA Compliant |
| UPC Code | 662774-005737 |
| Warranty | 3 years limited |
| Country of Origin | Taiwan |
