Extender | SKU: CE-H27811-S1

4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support

HDMI KVM Extender
4K60Hz
Up to 230ft (70m)
Touch Screen Support
Audio Extractor
$419.99
Shipping calculated at checkout.
Product Features

KVM Extender Over CAT Cable

This HDMI KVM extends USB keyboard, mouse (wireless ones supported), and HDMI signals up to 230FT (70 meters) over CAT 6/ 6e/ 7 cables. Remember this extender supports only point-to-point transmission, not over IP. We recommend good quality copper CAT cables.

Uncompressed HDMI Signals

This KVM supports HDMI data transmission up to 4K60Hz refresh rate near Zero latency. It also supports PCM audio (2 channels), digital 5.1 channel sound, and audio extraction from a S/PDIF Toslink audio jack on the Receiver (RX) to an external speaker. An additional HDMI output is located on the Transmitter (TX) to allow you to connect to a local display or monitor with an HDMI cable for monitoring.

S/PDIF Audio & Touch Screen Control

The S/PDIF (Toslink) port located on the Receiver allows you to extract digital audio to the audio system or external speaker. Meanwhile, not only can you control your remote computer with a keyboard and mouse, but also control it with a touchscreen panel

Easy to Use

No drivers required for setup. Simply plug and go to enable the use of a computer, DVR, NVR, and more devices control 230FT away. There are limitless applications on the KVM extender, such as offices, schools, public kiosks, hospitals, and call centers. It helps you secure computer consoles from public access.

Metal Housing Design

Protects the inside PCBA, also enhance the heat dissipation for better performance. Military-grade component for long service life

  • 45 Days Free Return

  • 2 Years Warranty

  • Lifetime Technical Support

  • The Advantage of HDMI Extension via CAT Cable

    The advantage of HDMI signals over ethernet cable is long-range, low cost, and remote control capability.

  • USB 2.0 Signal Extension

    To control a computer or device from a remote location with a keyboard and mouse connected to those USB 2.0 ports located on the Receiver (RX).

  • Advantage of Touch Screen Control

    With touch screen devices, you become independent of additional input devices. They offer direct navigation and accessibility featuring physical touch control. It minimizes the use of a traditional computer mouse and keyboard because it provides a faster more efficient way to interact with a computer system.

    Features

    • 4K@60Hz HDMI KVM Extension up to 230ft – Extends HDMI and USB 2.0 signals up to 230ft (70m) over Cat6/6e/7 for smooth long-distance AV transmission.
    • Remote KVM & Touch Control –Control your computer via keyboard, mouse, or touchscreen from the receiver side for flexible operation.
    • S/PDIF Audio Extraction & Loop-Out– Extract digital audio via Toslink (S/PDIF) and monitor locally with HDMI loop-out on the transmitter.
    • Reliable & Protected Design –Built-in lightning, surge, and ESD protection with durable metal housing for stable long-hour use.
    • Plug-and-Play Versatility – No drivers required; ideal for offices, classrooms, events, retail, and security setups.

    4K HDMI KVM Extender Over CAT6/ 6e/ 7 Cable up to 230ft Support Touch Screen with S/PDIF Audio Extraction & HDMI Loop Out

    Transmits 4K@60Hz HDMI and USB 2.0 Signals up to 230ft (70m) via Cat6/6a/7 Cable

    HDMI KVM Extender - Use a One Set of Keyboard & Mouse or Touchscreen for Remote Control

    Extend Distance - Extends/splits HDMI Signals up to 230ft (70m) Through RJ45 Network

    Multiple Connectivity Ports

    4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support
    View details
    HDMI USB KVM Over Cat6 Extender - 70m
    View details
    4K HDMI USB KVM Extender over Cat6 - Up to 230 feet - Zero Latency - ESD Protection - Metal Housing
    View details
    HDMI 4K30Hz KVM Over IP Extender - 120m(394ft) - Over IP KVM Extender - One to Many - HDMI Loop-out - Downscaler - Low-latency
    View details
    Full HD Wireless HDMI KVM Extender with Loopout, 1080p, up to 500ft (150m), HDMI Loop-out 4K60Hz
    View details
    SKU
    SKU
    CE-H27811-S1
    CE-H27411-S1
    CE-H28411-S1
    CE-H27R11-S1
    CE-H26G11-S2
    Connection port
    Connection port
    3x HDMI, 3x USB-A, 3.5mm, 2x RJ45, 2x Power Jack
    3x HDMI, 3x USB-A, 3.5mm, 2x RJ45, 2x Power Jack
    3x HDMI, 3x USB-A, 2x RJ45
    3x HDMI, 3x USB-A, 2x RJ45
    3x HDMI, 3.5mm, USB-A, 3x Micro USB
    Data Transfer (Max)
    Data Transfer (Max)
    18Gbps
    10.2Gbps
    10.2Gbps
    10.2Gbps
    10.2Gbps
    Additional function
    Additional function
    Audio Extractor, KVM, Support Touch Screen
    Audio Extractor, KVM
    KVM
    KVM, HDMI Loopout, One to many, Downscale
    IR, KVM, USB
    Housing material
    Housing material
    Metal
    Metal
    Metal
    Metal
    Metal
    Color
    Color
    Black
    Black
    Black
    Black
    Black
    Dimensions
    Dimensions
    TX/RX: 6.02” (L) x 0.87” (H) x 4.15" (W) (15.29 cm x 2.21 cm x 10.54 cm)
    TX/RX: 3.35” (W) x 0.79” (H) x 2.95" (D) (8.51 cm x 2 cm x 7.49 cm)
    TX/RX: 3.03" (W) x 0.83" (H) x 2.36" (D (7.7 cm x 2.11 cm x 5.99 cm)
    TX/RX: 4.09" (W) x 0.91" (H) x 4.41" (D) (10.39 cm x 2.31 cm x 11.20 cm)
    TX/RX:6.18" (W) x 0.83" (H) x 3.15" (D) (15.7 cm x 2.11 cm x 8 cm)
    Weight
    Weight
    TX/RX:0.77 lbs
    TX/RX:0.29 lbs
    TX/RX: 0.27 lbs
    TX/RX:0.47 lbs
    TX/RX:0.71 lbs
    Mountable
    Certification/ Standards
    Certification/ Standards
    FCC / CE / RoHS
    FCC / CE / RoHS
    FCC / CE / RoHS
    FCC / CE / RoHS
    FCC / CE / RoHS
    Warranty
    Warranty
    2 years
    2 years
    2 years
    2 years
    2 years
    Country of Origin
    Country of Origin
    China
    China
    China
    China
    China
    Supported External Displays
    Supported External Displays
    1 display
    1 display
    -
    -
    -
    Resolution
    Resolution
    Up to 4K60Hz
    Up to 1080p 60Hz
    Up to 4K30Hz
    Up to 4K30Hz
    TX: Up to 4K60Hz, RX: Up to 1080p 60Hz
    Power Delivery
    Spec
    Spec
    HDMI 2.0, HDCP 2.2, USB 2.0
    HDMI 1.3, HDCP 1.4, USB 1.1
    USB 1.1, HDMI 1.4, HDCP 1.4
    USB 1.1, HDMI 1.4, HDCP 1.4
    HDMI 2.0, HDCP 2.0, HDCP 1.3
    Protocol
    Protocol
    USB, HDMI
    USB, HDMI
    Passthrough
    TCP/IP
    -
    Power Output (Max)
    Power Indicator
    Power Indicator
    -
    -
    Yes
    Yes
    Yes
    Protection
    Protection
    ESD
    ESD
    ESD
    ESD
    ESD
    Power Adapter
    Power Adapter
    5V/2A
    5V/1A
    5V/1A
    5V/1A
    5V/2A
    Form Factor
    Frequency
