IT-Cables |
SKU:
CB-DP0Y11-S1
3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA)
Mini DisplayPort
VGA
Converter
Regular price
$24.99
Unit price
/
Unavailable
Shipping calculated at checkout.
3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
Mini DP to VGA Cable
Mini DP to VGA Cable
Video Resolutions
Video Resolutions
Auto Device Detection
Auto Device Detection
Wide Compatibility
Wide Compatibility
Compliant & Protection
Compliant & Protection
No content found
| Chipset | ANX9832 |
| Standard Compliance | Compliant with DisplayPort 1.1a standard |
| Resolution Support | Up to 1920x1200 or HDTV resolutions up to 1080p |
| PC Display Modes | VGA, SVGA, XGA, SXGA, UXGA and WUXGA |
| HDTV Display Modes | 480i, 576i, 480p, 576p, 1080i and 1080p |
| Video Support | Supports RGB analog video (VGA port) Supports 8-bit per color RGB format |
| Advanced Features | Supports full DisplayPort link training Supports EDID and MCCS pass-through Supports Down Spread Spectrum (SSC) |
| ESD Protection | 8KV |
| Connectors | 20-Pin Mini DisplayPort (male) to 15-pin VGA (male) Gold plated |
| System Requirements | Device with a Mini DisplayPort output VGA monitor or display |
| Product | |
| Product Dimensions | 0.91 m (3ft) |
| Product Weight | 0.13 lbs |
| Unit Package | |
| Unit Package Dimensions | 7.48″(W) x 9.84″(H) |
| Unit Package Weight | 0.15 lbs |
| Master Carton | |
| Master Carton Dimensions | 18.11″(W) x 11.81″(H) x 11.81″(D) |
| Master Carton Weight | 16.40 lbs |
| Master Carton Quantity | 100pcs/ctn |
| Package Contents | 3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA) |
| Color | White |
| Material | Plastic |
| Environmental Conditions | Operating temperature: 32 to 140°F Storage temperature: 14 to 158°F Relative humidity: < 85% non-condensing |
| Certifications/Standards | FCC, CE, RoHS |
| Warranty | 3 years limited |
| Country of Origin | China |
