3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA)
3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
Mini DP to VGA Cable
Mini DP to VGA Cable
Video Resolutions
Video Resolutions
Auto Device Detection
Auto Device Detection
Wide Compatibility
Wide Compatibility
Compliant & Protection
Compliant & Protection
-
45 Days Free Return
-
2 Years Warranty
-
Lifetime Technical Support
| Hardware | |
| Chipset | ANX9832 |
| Video | |
| Standard | DisplayPort 1.1a compliant |
| Resolution | Up to 1920x1200 or HDTV resolutions up to 1080p |
| PC Display Modes | VGA, SVGA, XGA, SXGA, UXGA and WUXGA |
| HDTV Display Modes | 480i, 576i, 480p, 576p, 1080i and 1080p |
| VGA | Supports RGB analog video Supports 8-bit per color RGB format |
| Advanced Features | Supports full DisplayPort link training Supports EDID and MCCS pass-through Supports Down Spread Spectrum (SSC) |
| ESD Protection | 8KV |
| Interface | 1x 20-Pin Mini DisplayPort, male 1x 15-pin VGA, male |
| System Requirements | - Device with a Mini DisplayPort output - VGA monitor or display |
| Package Contents | 1x 3ft Mini DisplayPort to VGA Converter Cable (mDP to VGA) |
| Certifications/Standards | FCC, CE, RoHS |
| UPC Code | 662774-020549 |
| Warranty | 3 years limited |
| Country of Origin | China |
| Product | |
| Length | 3ft (0.91m) |
| Weight | 0.13 lb (0.06 kg) |
| Color | White |
| Housing Material | Plastic |
| Connector Plating | Gold plated |
| Unit Package | |
| Dimensions (L) x (H) | 7.48″ x 9.84″ 19.00 cm x 24.99 cm |
| Weight | 0.15 lb (0.07 kg) |
| Master Carton | |
| Dimensions (L) x (H) x (W) | 18.11″ x 11.81″ x 11.81″ 46.00 cm x 30.00 cm x 30.00 cm |
| Weight | 16.40 lbs (7.44 kg) |
| Quantity | 100 pcs/ctn |
| Environmental Conditions | |
| Operating temperature | 32° to 140° F |
| Storage temperature | 14° to 158° F |
| Relative humidity | < 85% non-condensing |
