Splitter |
SKU:
CE-H21Q11-S1
35% off
HDMI® Splitter for 10 Displays, 4K & 3D
HDMI Splitter
1 In / 10 Out
4K30Hz
USB Firmware Update
Metal Housing
Sale price
$195.95
Regular price
$299.99
Unit price
/
Unavailable
Shipping calculated at checkout.
HDMI® Splitter for 10 Displays, 4K & 3D is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
4K Ultra HD & Full HD Support
4K Ultra HD & Full HD Support
Advanced HDMI Features
Advanced HDMI Features
High-Speed Performance
High-Speed Performance
Premium Build & Easy Setup
Premium Build & Easy Setup
Wide Audio & Format Compatibility
Wide Audio & Format Compatibility
No content found
| Hardware | |
| Chipset | Lontium LT86104EX |
| Video | |
| Standard | HDCP 1.4 compliant |
| Bandwidth | 10.2Gbps |
| Wide Frequency Range | 2 5MHz to 340MHz |
| Resolution | 480i / 480P / 576i / 720p / 1080i / 1080p / 4Kx2K |
| Display Mode | Mirror |
| Transmission Distance | Up to 20m (5m input, 15m output) |
| Audio | |
| Audio Format | Standard, DSD and HD (HBR) |
| TMDS Signal | Input: up to 1.2V (peak-to-peak) |
| DDC Signal | Input: up to 5V (peak-to-peak, TTL) |
| LED | Power LED indicator |
| Power Adapter | |
| Input | 100-240VAC, 50 / 60 Hz |
| Output | 5V / 3A |
| Interface | 1x 19-pin, HDMI, Type A, female, input 10x 19-pin, HDMI, Type A, female, output 1x 4-pin, USB, Type B, female, Firmware update |
| Package Contents | 1x10 HDMI Splitter with 3D and 4Kx2K 1x Power adapter 4x Housing rubber pads 1x Installation guide |
| Product | |
| Dimensions (L) x (H) x (W) | 7.68" x 3.78" x 1.08" 19.51 cm x 9.60 cm x 2.74 cm |
| Weight | 0.95 lb (0.43 kg) |
| Color | Black |
| Housing Material | Metal |
| Unit package | |
| Dimensions (L) x (H) x (W) | 10.38″ x 3.06″ x 6.88″ 26.37 cm x 7.77 cm x 17.48 cm |
| Weight | 1.87 lbs (0.85 kg) |
| Master carton | |
| Dimensions (L) x (H) x (W) | 15.94″ x 14.17″ x 11.81″ 40.49 cm x 35.99 cm x 30.00 cm |
| Weight | 20.94 lbs (9.50 kg) |
| Quantity | 10 pcs/ctn |
| Environmental Conditions | |
| Operating Temperature | 32° to 158° F |
| Storage Temperature | 14° to 176° F |
| Relative Humidity | 0% to 90% RH (non-condensing) |
| Certifications/Standards | FCC, CE, RoHS |
| UPC Code | 662774-018416 |
| Warranty | 3 years limited |
| Country of Origin | China |
Q1: Can this extend to 10 different screens?
Q1: Can this extend to 10 different screens?
A1: No, it can not extend to 10 different screens. All splitter outputs will always have the same screens.
